BPA-1511, BPA-2511
Furimach
84778000
Key Feature of BPA-1511 Fully Automatic Adhesive Tape Slitting Machine
1. Speed and Efficiency: Fully automatic machines operate at high speeds (up to 300m/min), significantly enhancing production efficiency by reducing downtime and minimizing labor costs.
2. Automatic Tension Control: The machine ensures consistent unwind & rewind tension throughout the slitting process, preventing tape from stretching or loosening.
3. Unwinder BOPP Tape Jumbo Roll Monitoring: The machine is equipped with a jumbo roll camera that allows operators to visually monitor the unwinding process in the front side. When the jumbo roll reaches a minimal size, an automatic alert notifies the operator to replace a new jumbo.
4. Automatic Labeling: The machine features an integrated automatic labeling system, boosting productivity and ensuring accuracy and efficiency.
5. Auto Cut-Off and Smoothing: Once the desired length is reached, the machine automatically cuts the finished tape rolls and smooths the tape ends, providing a neat finish for each tape roll.
6. Auto Core Loading and Tape Unloading: The system automatically handles paper core loading and finished tape unloading, improving operational efficiency.
7. On-line Packaging (Optional: Tower Type Packing Machine, Flatbed Type Packing Machine): After slitting, the machine automatically rewinds the tape into smaller rolls or spools, which can then be seamlessly connected to an online packaging system. Options include tower packaging, flatbed packaging, or individual sleeve labeling and packaging for enhanced workflow.
8. Remote Troubleshooting: In the event of an issue, our technicians can access the system remotely to diagnose and resolve problems quickly, reducing downtime and maintaining smooth operation.
1.6M Wide Fully Automatic BOPP Tape Slitting Machine Working with Tower Type Tape Packing Machine
2.0M Wide Fully Automatic BOPP Tape Slitting Machine Working with Flatbed Type Tape Packing Machine
Optional Items
1. Super clear press roller for super clear BOPP tape production purpose
2. Size setting mould (Size Setting Mould: with the machine, we will provide one set of mould for size setting. Additional sizes are available upon request; however, we recommend limiting production to 1-2 sizes for mass production. Frequent mould changes and adjustments can be time-consuming and may impact production efficiency.)
3. Low-noise BOPP tape production corona treatment device (customers can also buy corona treatment device on their own and provide us the installation dimension drawing so that we will leave the proper space for the corona treater's mounting.)
Main Technical Parameters
Model | BPA-1511-1.3M | BPA-1511-1.6M | BPA-1511-2.0M |
Effective width | 1300 mm | 1600 mm | 2000mm |
Max. unwind diameter | 800mm | 800mm | 800mm |
Min. slitting width | 18mm | 18mm | 18mm |
Max. rewind diameter | 150mm | 150mm | 150mm |
Max. working speed | 300m/min | 300m/min | 300m/min |
Slitting blade (razor blade) | 0.2×22×60mm | 0.2×22×60mm | 0.2×22×60mm |
Slitting blade (optional) | Air blade | Air blade | Air blade |
Machine dimension (L*W*H) | 8.5*4.4*2.2M | 9.4*4.4*2.2M | 10.6*4.4*2.2M |
FAQ
1. How many operator required for this machine?
If you only operate one auto slitter, one operator is enough; if you also connect with auto paper core cutting machine and tape packaging machine, we recommend two operators.
2. Can I connect with auto paper core cutting machine?
Yes, Furimach also provides fully automatic paper core cutting machine to work online
3. How much space required for this machine?
Take 1.6m slitter for example, please check below floor space layout
4. Can I convert masking tape jumbo rolls on this machine?
Furimach can provide both razor blades and air blades to convert maskign tape jumbo rolls.
Please watch the below video:
Fully Automatic Masking Tape Slitting Machine Video
