SLF-1300, SLF-1600
Furimach
84411000
Features:
Ø Duplex rewind shaft turret exchange system
Ø Rewind driving unit: three-motor drive system: two rewind servo motors combined with the main one. Unwind and rewind tension isolation is done by main motor, so the finished product tension is stable with nice appearance.
Ø Rewind unit: rewind can work for both gap & lay-onmodes by adopting the trolley. Lay-on mode contactpressure is adjustable and gap mode can work for discontinuous winding, suitable for various materials.
Ø Electrical unit: LCD touch panel is used for setfing tension,length,etc.The control system adopts Siemens PLC tocontrol movements with self-detection function,so errorcan be detected automatically.
Ø Unwind unit: Customer can choose a connected feeding machine base to save space, or a separate feeding machine base with a larger feeding diameter, which increases the possibility of installing other devices in the space.
Main Technical Parameters
| Machine width | 1.3M 1.6M |
| Min. slitting width | 20mm |
| Max. rewind diameter | 500mm |
| Max. unwind diameter | 1000mm |
| Working speed | Max. 300m/min |
| Paper core I.D. | 3"/6” |
Optional Items:
Ø Automatic jumbo roll loading device: optional for both shaft type and shaftless type.
Ø Automatic tabbing device: suitable for bare glue materials.
Ø Slitting moveable shear blades: fast blade adjust with digital display, accuracy±0.1mm
Ø Unwind noise hood: to reduce the noise and improve the quality and safety of the working environment.
Ø Splice table: to connect the front and rear materials to improve the evenness of the material and improve efficiency.
Ø Automatic web cut-off device: flying knife or tooth knife.
Ø Automatic smoothing device: suitable for adhesive materials.
Ø Differential shafts or air shafts. Automatic of load device and unloading rack.
Application of the Four-shaft Slitting Machine
