Feature
1. The entire machine is constructed from stainless steel, ensuring excellent water resistance and durability.
2. Equipped with an adjustable cutter pan and double-face blade, designed for a long service life through unique spiral cutting technology.
3. A single positioning center pillar ensures more stable label feeding.
4. The label positioning group enhances labeling precision.
5. The machine features a user-friendly touch control system for easy operation.
6. Optional independent feeding and labeling system simplifies operation and reduces costs.
7. The machine utilizes PLC programmable control system, along with imported brand servo motors, servo drivers, inverters, and sensors, ensuring accurate, fast, and stable labeling & packing performance.
8. Optional: packing roll side labeling unit.
Main Technical Parameter
Power Source | AC380V 50Hz/60 Hz |
Packing tape diameter | ¢80-150 (for 3” core tape) |
Packing speed | 60-70pcs/min |
Packing tape height | 12-80mm (for 3” core tape) |
Labeling accuracy | +/-0.1mm |
Air Pressure(Kg/cm2) ) | 5 |
Label Material | PVC film (thickness: 40micron) |
Machine Dimension(mm) | L7460*W1210*H2090mm |
Machine Weight(Kg) | Approx. 1400KG |
How does the Packing Machine Works?
