Main Features & Benefits:
Dual Function: Integrates both slitting and rewinding in one machine.
High Efficiency: High-speed design for productive output (linear speed up to 500M/min).
Precision & Consistency: Ensures accurate slitting and smooth rewinding to minimize waste.
Operation Control: Variable frequency drive (VFD) control, enabling stepless speed adjustment.
Productivity Tool: This machine is an ideal and cost-effective rewinding/slitting solution, featuring easy and flexible adjustment, low noise operation, dual-shaft rewinding, and an automatic rewinding counter.
Quick Shaft Change: Suitable for shafts change for 1", 2", and 3" paper tubes.
Main Technical Parameters
| Effective width | Max. 500mm |
| Min. slitting width | 50mm |
| Jumbo roll loading mode | By hand |
| Max. unwind diameter | 400mm |
| Max. rewind diameter | 200mm |
| Max. mechanical speed | 500m/min |
| Inner core I.D. of Jumbo | 3" |
| Core of finished rolls | 1”, 2”, 3” |
| Slitting blade | Razor blade |
| Finished roll cutting mode | Manual knife cut |
| Machine voltage | 380V 50HZ 3P |
