Main Feature:
1. High production: linear speed up to 400/min, daily production up to 20T/day.
2. Three-shaft exchange system, servo driven, the finished product of stretch film has better tackiness, stretchability, and puncture resistance.
3. Easy operation: one operator is enough to manipulate the whole machine.
4. High automation: machine has function of auto paper core loading, finished roll unloading, etc.
5. Automatic online thickness guage: this device ensures uniform thickness of the finished stretch film.
6. High technology: with multi-layer co-extrusion technology, it’s flexible in raw material usage and low formula cost to meet different requirements.
Technical Parameters
| Product | PE Stretch film |
| Finished product width | 2000mm (500mm*4 rolls, 250mm*8 rolls) |
| Die width | 2400mm |
| Stretch film thickness | 0.012-0.035mm |
| Main raw material | LLDPE, LDPE & MLLDPE |
| Screw Diameter | 65/115/115/65mm |
| Screw L/D Ratio | 30D |
| Raw materials used | LLDPE, MLLDPE and other raw materials |
| Film layer structure | D/A/C/B/D A/D/C/D/B |
| Extrusion capacity (MAX) | 920kg/h |
| Linear speed (MAX) | 400m/min |
| Power supply | 380V 50HZ 3P |
