| 1. Automatic length setting: the two-step length counter provides accurate rewinding length control. Once the set length is reached, a servo motor is adopted so that shafts will instantly and automatically changes, ensuring easy operation and efficient performance. |
| 2. Programmable controller: the high performance programmable controller offers convenient control of the entire rewinding operation. Both length and tension are accurately displayed by LCD readout. |
| 3. The paper core is held firmly on the pneumatic shaft. With easy, fast loading and unloading, it greatly improves efficiency. |
| 4. Automatic smoothing device: this wipe down device fully eliminates the problem of wrinkling and air bubbles in the product after rewinding. This device further ensures the smoothness of product. |
| 5. Hydraulic auto up-lifter device (optional): this device offers easy material loading for operational convenience and improves efficiency. |
| 6. The pressing roller is controlled by the cylinder and the pressure is adjustable. The semi-finished products are properly pressed to ensure smooth, stable running during rewinding. |
| Effective width | 1.3m 1.6m |
| Max. unwind diameter | 800 mm |
| Max. Rewind diameter | 300mm |
| Max. Working speed | 180M /Min |
| I.D. of paper core | 1"-3" |
| Main motor | 5HP*2 |
| Air pressure | 6Bar |
| 1. Automatic length setting: the two-step length counter provides accurate rewinding length control. Once the set length is reached, a servo motor is adopted so that shafts will instantly and automatically changes, ensuring easy operation and efficient performance. |
| 2. Programmable controller: the high performance programmable controller offers convenient control of the entire rewinding operation. Both length and tension are accurately displayed by LCD readout. |
| 3. The paper core is held firmly on the pneumatic shaft. With easy, fast loading and unloading, it greatly improves efficiency. |
| 4. Automatic smoothing device: this wipe down device fully eliminates the problem of wrinkling and air bubbles in the product after rewinding. This device further ensures the smoothness of product. |
| 5. Hydraulic auto up-lifter device (optional): this device offers easy material loading for operational convenience and improves efficiency. |
| 6. The pressing roller is controlled by the cylinder and the pressure is adjustable. The semi-finished products are properly pressed to ensure smooth, stable running during rewinding. |
| Effective width | 1.3m 1.6m |
| Max. unwind diameter | 800 mm |
| Max. Rewind diameter | 300mm |
| Max. Working speed | 180M /Min |
| I.D. of paper core | 1"-3" |
| Main motor | 5HP*2 |
| Air pressure | 6Bar |
